MaxTrac 902430 3" Rear Lift Kit w/Shocks Fits 2009–2024 Ram 1500 2WD (5-Lug)

Upgrade your Ram with the MaxTrac 902430 rear lift kit and get the height, stance, and performance your truck needs. This system provides a true 3-inch rear lift while maintaining factory ride quality, making it ideal for daily driving, towing, or building a leveled lift setup.

Engineered for durability and proper suspension geometry, this kit includes heavy-duty lift coils, correction brackets, and matched MaxTrac rear shocks. The result is improved stability, better handling, and increased clearance for larger tires.

Fitment
2009–2024 Ram 1500 2WD 5-lug models
Does not fit 6-lug models

Designed to pair with MaxTrac part number 702145 for a complete 4.5-inch lift system

Features
Provides a 3-inch rear lift for improved stance and tire clearance
Heavy-duty lift coils for strength and long-term performance
Track bar bracket helps maintain proper alignment after lifting
Sway bar brackets improve stability and suspension geometry
Includes MaxTrac rear shocks tuned for lifted applications
Grey powdercoat finish for corrosion resistance and durability

What’s Included
Rear lift coils
Track bar bracket
Sway bar brackets
Two MaxTrac rear shocks 2800LL-4
Installation hardware

Important Notes
Models with 2-piece driveshaft require carrier bearing kit part number 612400
Shocks are sold individually if purchased separately and require ordering two
Not recommended for wheels wider than 9 inches or less than 4.5 inches backspacing as it may void warranty

Specifications
Lift Height 3 inches rear
Material steel
Finish grey powdercoat
Weight 55 pounds
Dimensions 28 x 14 x 8 inches
UPC 738283444289
